2- Prepared Vmware for Install MikroTik

 We have 4 tools to study MikroTik OS

• Vmware workstation
• Virtual Box
• EVE-NG
• GNS3

- VMware Workstation: is a powerfull desktop virtualiztion software that allows you to run

                                              multiple operating system on a single PC

-Vitrtual Box: like Vmware Workstation

-EVE-NG: (Enterprise Virtual Environment - Next Generation) is a powerful network

                    emulation platform that allows you to create and test complex network

                    topologies in a vitualized environment

-GNS3: (Graphical Network Simulator-3) is a powerfull open-source software that allow you

               to design,  simulate, and test virtual  networks with complex topologies.

This environment we use Vmware workstation and EVE-NG

1. Open Vmware workstion
2. Create a New Virtual Machine
3. It show new dialog box chose Typical click Next

 4.Select on Installer disk image file (iso), fine file iso  to install OS, click Next

5. Guest operating system select Other and version Orther

6. Virtual machine name: (Set name of Virtual machine name)

    Location: Find location you want to put like Drive C or D, click Next

7-This point is very important

            Maximum disk size: Set size depend on request

            Store virtual disk as a single files: It mean that you virtual machine store only one file

            Split virtual disk into multiple files: It mean that is store separate file and get storage depend on Vm file size and click Next

8-Click custome Hardware, If you want to add RAM, HDD, or CPU more, click finish, if you want to update
